aluminum-composite-panels

Aluminum Composite Material (ACM): A lightweight, engineered substrate made of two pieces of aluminum sandwiching a polyethylene core. Ideal for indoor or outdoor use, offering dimensional stability, low weight, and a sleek, vibrant appearance.

ACM metal panels are both attractive and practical for use in visual merchandising, framing, archiving, commercial interiors and exteriors, construction, and fine art applications. Check out what we can offer below!

Max dimentions:
1220mm(width)x2440(length)
2.5mm x 5mm(thickness)

The thickness of aluminum foil
from 0,15mm to 0,6 mm

Bond Strength 3kgf/cm

The production of ACP with custom size and color is available on request

No	Composition			Panel thickness	Type of facial covering
No	The front surface of the aluminum-coated	Filler	Aluminum surface of the backside with 2PE coating	Panel thickness	Type of facial covering
1	0,21 - 0,6mm	Hardly combutsly (Polymer-mineral)	0,21 - 0,6mm	3,0 - 6,0mm	PVDF (Polyvinylidene fluoride)
2	0,18 - 0,6mm	Compound	0,18 - 0,6mm	2,5 - 6,0mm	PVDF (Polyvinylidene fluoride)
3	0,21 - 0,6mm	Hardly combutsly (Polymer-mineral)	0,21 - 0,6mm	3,0 - 6,0mm	2PE (double polyester)
4	0,18 - 0,6mm	Hardly combutsly (Polymer-mineral)	0,18 - 0,6mm	2,5 - 6,0mm	2PE (double polyester)

Aluminum Composite Panels
